Extra Third Shaft For Lathe

7,900

– Recommended for Machines Lengthier than 1 mtr – Sudden Reverse/Forward/Stop – More Production – Operator Friendly The bevel box by which means the action of third-shaft control rod was made to pass through the bed and engage with the rear-mounted headstock clutch lever.

Enquiry
  • Some versions of the lathe were fitted with a spindle-direction control shaft  below and parallel to the leadscrew with an operating handle (A) fastened to the right-hand face of the apron.
  • Fitted with a conventional spoked wheel for movement by hand, the apron carried both leadscrew and power-shaft driven feeds; the 32 mm (1.26″) diameter leadscrew was engaged only for screwcutting (and carried a torque-limiter) whilst the powershaft provided the sliding and surfacing feeds used in normal work. A push/pull button selected the power sliding and surfacing feeds, with engagement by single lever in the middle of the apron
  • The bevel box by which means the action of third-shaft control rod was made to pass through the bed and engage with the rear-mounted headstock clutch lever.



Essential Advantage :-

  • Recommended for Machines Lengthier than 1 mtr
  •  Sudden Reverse/Forward.
  • Emergency  STOP machine
  • More Production
  • Operator Friendly



Accessory Suitable Model Price (Rs.)
Extra Third Shaft All Models 7900
